Echo Fix EF-P2

We like these. The compact, solid build and utilitarian aesthetic is great. They sound... big. Certainly much, much bigger than the small (but cleverly designed/packed) springs you can see through the observation window would suggest. They have a great (adjustable) tone and a very pleasing, lengthy decay to the tails. If you are looking for a real mono reverb that sounds like a real reverb then this is for you.

Echo Fix say:

The Echo Fix EF-P2 is a real Spring Reverb pedal that packs a huge sound into a small enclosure. The EF-P2 features a three-spring reverb tank, adjustable Spring Drive, Bass / Treble EQ controls, and Reverb Volume control. With a footswitch for reverb bypass and also a direct signal mute footswitch, the EF-P2 can also be used as an outboard effect in recording studios. With increased voltage rails for studio use, the EF-P2 can accept line level inputs from synths and other audio devices, not just guitar.

Features:

• Real spring reverb pan


• Spring drive control


• Bass control


• Treble control


• Reverb Level Control


• Soft momentary switching for noiseless


• Bypass and Direct Mute switching


• Increased internal power supply voltage rails for increased dynamic range


• Illuminated reverb tank viewing window

Power - 9VDC Centre Negative

Current - 200mA minimum

Input Impedance - 1MΩ

Output Impedance - 1KΩ

Dimensions - 160mm x 130mm x 60mm (6.29" x 5.11" x 2.36")
